Serial number

Fault phenomenon

Cause analysis

Treatment method

1

The front and rear switches of the cylinder are abnormal

Cylinder stuck or no air pressure

Check the air pressure, check whether the cylinder is mechanically stuck, check whether the cylinder magnetic switch is damaged, if there is a problem, replace it in time.

2

Material blocking alarm

The fiber amplifier is blocked

Check whether the fiber amplifier is blocked by foreign bodies or workpieces, and remove the materials in time.

3

There is no voltage in the slide spreader

The short circuit protector works

Check whether the circuit is overloaded or short-circuited, and reconnect the short-circuit protector after no fault.

4

Pressure anomaly

No air source access

Access the air source and open the hand slide valve.

5

Cylinder action is slow or too fast

Throttle adjustment position is not appropriate

Adjust the throttle.
