In the last installment, we learned about display columns, amplifiers, flowmeter tubes, balance states, full range values, etcaerometerRelated professional terms, this time we will learn about other term definitions! I believe that after reading this article, you will be more handy when using the instrument!

    magnification: The size increment given by the amplifier. towards aerometerIn the system of adjustable magnification, this adjustment is achieved by using the calibration gauge to adjust the size of the back pressure, and for the system with a fixed magnification, in order to obtain precise measurement values, it can only put forward higher accuracy requirements for the pneumatic probe.
    nozzle: Damping hole on the pneumatic measuring head for ejecting air to the workpiece to be measured. The diameter of the nozzle hole is determined by the pneumatic gauge system used. The number and position of nozzle holes are determined by the application of the measured workpiece.
    Resolution: Zoom in on the smallest increment in the range displayed. For example, Edmond's electric column diagram has a hundred index values, and the resolution is full scale1/100.
    Pressure regulating valve: aerometerA device used to regulate the flow or pressure of air. For example, a damping hole with precise dimensions, or a needle valve, or both.
    Zero positionThe process of determining the position of the measured range after amplification in the process of setting the magnification. The zero position is usually chosen at the midpoint of the full scale, and the displayed value can be located anywhere within the full scale range.
    Zero dimension: The expected value or nominal size of the measured size. In a back pressure system, the zero size is usually the middle of the maximum and minimum, while in a flow system, the zero size is usually the minimum.
